Medical sampling tube precision injection molding
| Product Name | TAIWAN technology precision molding company for medical sampling tube precision injection molding. |
| Mold Base | M333,S136,M340,1.2083 etc. |
| Cavity | 32 |
| Runner | Hot |
| Mold Base Brand | LKM, HAS CO, DME, self-control etc |
| Mold Life | 1,000,000 shots |
| Plastic Material | PP, |
| Tolerance | 0.02 mm |
TAIWAN technology precision molding company for medical sampling tube precision injection molding.
Our company has precision injection molding for medical sampling tube, medical test tube, medical extraction
tube, and so on.
We have the 100K grade clean room and advanced precision injection molding equipments, very precise detection
equipment. So we are a precision molding company.
I will introduce the medical sampling precision injection molding here.
This mold has 32 cavities, with hot runner system Husky.
The mold size is 550*600*580 mm, and its weight is 1200 kg.
This precision mold material M333, and the mold base 420
Cold water pressure:4.6~8.3 kgs/c㎡
Cold water export flow: 617-775L/min
Precision molding company should provide precision injection molding, precision injection molds.
Welcome your inquiry.
Thank you !
